Blanking Cap, 3” 1502 F, 1/2” NPT Tap, 15000 psi, STD Service

Blanking Cap, 3” 1502 F, 1/2” NPT Tap, 15000 psi, STD Service

The Blanking Cap, 3" FIG 1502 Female, with 1/2" NPT Tap, 15,000 PSI, Standard Service, is built to provide reliable sealing and system isolation for high-pressure applications in oilfield operations. Crafted from forged high-strength alloy steel, this cap ensures exceptional performance under extreme pressure. The female FIG 1502 threaded connection guarantees a secure, leak-proof seal, while the integrated 1/2" NPT tapped port enables easy installation of pressure gauges, bleed-off valves, or auxiliary instrumentation. Designed for standard service environments, it combines strength, reliability, and ease of use for demanding field operations.

Features:

• High-Strength Forged Construction: Provides superior durability, fatigue resistance, and extended service life under high-pressure conditions.

• Rated for 15,000 PSI: Engineered to handle extreme pressures safely and reliably.

• 1/2" NPT Tapped Port: Allows attachment of monitoring or venting equipment without disturbing the cap's sealing integrity.

• Female Threaded Connection: Precision-machined FIG 1502 female threads ensure a secure, tight, and reliable connection.

• Corrosion-Resistant Finish: Coated to protect against harsh operating environments and extend product life.

• API and Industry Standards Compliance: Manufactured to meet or exceed API pressure control specifications.

• Easy Field Identification: Clearly marked with pressure rating and service type for safe and efficient field operations.

Specifications and Technical Details:

• Size: 3 inches

• Figure Number: 1502

• Connection Type: Female Threaded (F) with 1/2" NPT Tapped Port

• Material: Forged high-strength alloy steel

• Pressure Rating: 15,000 PSI (working pressure)

• Surface Treatment: Corrosion-resistant coating

• Service Type: Standard Service

• Standards: API pressure control equipment standards compliant

• Temperature Range: Suitable for a wide range of standard oilfield operating temperatures

• Markings: Size, service type, and pressure rating clearly indicated

Application:
The 3" FIG 1502 Female Blanking Cap with 1/2" NPT Tap is ideal for isolating flowlines, valves, and other pressure control systems during maintenance, pressure testing, or shutdowns in standard service oilfield applications. The tapped port allows real-time pressure monitoring or controlled pressure relief, improving safety and operational flexibility without system disruption.
